A

Rev Code

N/A

not imported

B

Section

N/A

not imported

C

Task Number

25 characters

one entry

E/C Reference

Engineering/ Update/ Engineering Control

D

Source Task Reference

N/A

not imported

E

Access

25 characters max

multiple entries allowed

space delimited

Task Card Panels

Engineering/ Update/ Task Card/ Panel button

F

Preparation

not imported

not imported

G

Zone

25 characters max

multiple entries allowed

space delimited

Task Card Zones

Engineering/ Update/ Task Card/ Zone button

H

Description

250 characters

Task Card Description Field

AND

Engineering Control Description Field

Engineering/ Update/ Task Card

AND

Engineering/ Update/ Task Card

I

Skill Code

10 characters

one entry

Task Card Item Skills

If the skill code does exist a new entry will be created in Settings/Update/Skills.

Engineering/ Update/ Task Card/ Skills tab, Items button

J

Task Code

8 characters

one entry

Task Card Category Field (Transaction Code)

AND

Engineering Control Category Field (Transaction Code)

Engineering/ Update/ Task Card

AND

Engineering/ Update/ Engineering Control

K

Sample Threshold

If Threshold Field is blank, the program will take data from this field.

All data is the same as Threshold Field.

See Threshold Field

L

Sample Interval

If Interval Field is blank, the program will take data from this field.

All data is the same as Interval Field.

See Interval Field

M

Threshold

Note: The First Schedule in the Engineering Control, Schedule tab is pulled from this column when populated.

<time><time type>

where:
<time> = Numeric Digits
<time type>=2 char. code
YE = years
DY = days
MO = months
FH = flight hours
CY = cycles

Example:
300 CY
1000 FH

multiple entries

line delimited

In Excel use ALT+Enter to add multiple line delimited entries.

Engineering/ Update/ Engineering Control/ A/C CTL button/ Override

N

Interval

<time><time type>

where:
<time> = Numeric Digits
<time type>= 2 char. code
YE = years
DY = days
MO = months
FH = flight hours
CY = cycles

Example:
300 CY
1000 FH

multiple entries

line delimited

In Excel use ALT+Enter to add multiple line delimited entries.

E/C Repeat Schedule

Engineering/ Update/ Engineering Control/ A/C CTL button/ Override

O

Source

N/A

not imported

P

Tci

N/A

not imported

Q

Tps

N/A

not imported

R

Reference

25 characters

multiple entries

line delimited
In Excel use ALT+Enter to add multiple line delimited entries.

E/C Engineering Document

Engineering/ Update/ Engineering Control, Document button

S

Men

2 digit number

Task Card Item Skill Tab Men Required Field

Engineering/ Update/ Task Card/ Skills Tab, Items button

T

Task Mh

6 digit number
and 2 decimal places

multiple entries allowed

Task Card Item Skill Tab Man Hours Field

Note: When imported, the values in row U and V will be added to the value in row T.

Engineering/ Update/ Task Card/ Skills Tab, Items button

U

Acc Mh

6 digit number
and 2 decimal places

multiple entries allowed

Task Card Item Skill Tab Man Hours Field

Note: When imported, the values in row U and V will be added to the value in row T.

Engineering/ Update/ Task Card/ Skills Tab, Items button

V

Prep Mh

6 digit number
and 2 decimal places

multiple entries allowed

Task Card Item Skill Tab Man Hours Field

Note: When imported, the values in row U and V will be added to the value in row T.

Engineering/ Update/ Task Card/ Skills Tab, Items button

W

AC Effectivity

1,000 characters

multiple entries

space delimited

If field = ALL, then E/C and Task Card will be effective to all A/C in the system.

If field is blank, then there will be no A/C effectivity. (See notes.)

A/C Effectivity for E/C (A/C)

AND

A/C Effectivity for Task Card (A/C)

Note: When loading an MPD revision, if an Engineering Control is set up originally as a P/N E/C, but the MPD file has applicability against the aircraft, the system will override and remove the original P/N E/C effectivity and assign it to the aircraft effectivity. It is important that when this scenario is in effect, in order for the MPD Loader not to override the P/N E/Cs effectivity, the file must be amended by removing the aircraft effectivity against the Engineering Controls set up as a P/N E/Cs. When the aircraft applicability is removed and left blank, the system will retain the original P/N E/C effectivity.

Note: If this field is left blank in the import file, then there will be no A/C effectivity. However, if the A/C Effectivity Tab is populated with a Type/Series, then that Type/Series will override the blank effectivity field in the document and give effectivity to all Aircraft under that Type/Series.

Note: A/Cs must exist in the Aircraft Master.

Engineering/ Update/ Engineering Control/ A/C CTL button

AND

Engineering/ Update/ Task Card/ Effectivity button

X

Additional Description

2000 characters

Task Card Item 1

Engineering/ Update/ Task Card/ Item Button

Y

FSTOTAL

<time><time type>

where:
<time> = Numeric Digits
<time type>=2 char. code
YE = years
DY = days
MO = months
FH = flight hours
CY = cycles

Example:
300 CY
1000 FH

one entry allowed

Total Hours and Total Days. The system will convert months into days for the Total Days field.

Engineering/ Update/ Engineering Control, E/C Schedule Tab

Z

Task Type

10 characters

one entry

Task Card Type field

Engineering/Update/Task Card
