TRAX MANUALS > Planning > Planning Module > Planning, Query Menu > A/C Planning Query > A/C Planning (Interactive Planner View), General Tab > A/C Planning (Interactive Planner View) Results > Selected Work Order Area, via (A/C Planning) Interactive Planner > (A/C Planning) Interactive Planner, Selected Work Order Area, T/C Tab

The Engineering Control Tab allows the user to view all Task Cards related to the Work Order.

The following information/options are available in this window:
_____________________________________________________________________________________

W/O

The Work Order used to categorize, manage, and schedule work requirements for aircraft maintenance.

A/C

The individual aircraft tail number.

Task Card

The Task Card / Job Card that details the scheduled maintenance work.

Status

The status of the Task Card.

Task Card Description

Task Card Description.

P/N

The Part Number reference for the aircraft part.

P/N S/N

The Serial Number for the specific serialized part.

Corrosion checkbox

This checkbox is selected if this is a Corrosion Card. If this box is checked, the appropriately related field will appear on the Work Order.

SEQ

The Sequence Number. This number is generated from the number of times the Work Order Pack Print is printed (i.e. If there are ten Task Cards on a Work Order, and the Work Order has been printed twice from the Work Order Pack Print, for the first occurrence of the Work Order Pack Print, the Task Card would have a SEQ of one. For the second occurrence, the Task Card would have a SEQ number of 11.

_____________________________________________________________________________________

The Task Card button is also available in this tab for additional functionality.
